Single-position PCB terminal blocks for LED applications

Press Release   •   May 19, 2014 10:43 BST

Phoenix Contact is further expanding its PTSM series with a single-position version for LED applications. With a horizontal connection direction to the PCB, the compact SMD PCB terminal block is delivered in tape-on-reel packaging like the versions with higher position counts, making it suitable for automated soldering processes.

The terminal in a 2.5 mm pitch is designed for wires up to 0. 5 mm². Thanks to the push-in connection method, the wires can be quickly and effortlessly connected once they have been stripped.

The PTSM series features a low-profile design, making it especially well suited for LED applications. The range includes plugs, PCB terminals, and board-to-board connectors. Black or white housings are available for use in different applications.

With its new single-position PCB terminals from the PTSM series, Phoenix Contact is expanding its range of compact PCB terminals designed specifically for today’s LED lighting applications

Phoenix Contact, founded over 80 years ago, is a leading manufacturer of electric connection and industrial automation technology. 12,800 employees, 47 own sales companies and 30 sales partner worldwide ensure customer proximity.

Our work is dedicated to the creation of progress with inspiring, innovative solutions and to a trusting partnership towards our customers and partners with common benefits.
