Unique combination of floating and high speed

Press release -

Unique combination of floating and high speed

The new FS 0,635 series board-to-board connector with floating functionality from Phoenix Contact offers a high tolerance compensation of ±0.7 mm in the x and y directions. With a pitch of 0.635 mm, this tolerance is greater than the pitch itself. In the z direction, a plug-in tolerance of 0.6 mm is also possible.

This flexibility within the board-to-board connection minimises mechanical strain and provides a reliable connection. These properties are particularly important in environments with high vibration, when using several board-to-board connectors side by side, or for automatic insertion using robots.

The combination of floating and high speed is unique on the market: Despite the curved contact of the floating version, it achieves a data transmission rate of up to 40 Gbps. As an additional service, Phoenix Contact offers its customers design-in support with high-speed simulations and S-parameters. The floating female connector strip is combined with a fixed rigid male connector strip. In the FS 0,635 series, stack heights between 8 and 12.6 mm are thus achieved with the floating principle. As a standard rigid board-to-board connection, stack heights between 6 and 16.6 mm can be realised. The entire series is available now in the four numbers of positions 20, 40, 60, and 80 via the free sample service.

Topics

Categories


Phoenix Contact, founded over 80 years ago, is a leading manufacturer of electric connection and industrial automation technology. 14000 employees, 50 own sales companies and 30 sales partners worldwide ensure customer proximity.

Our work is dedicated to the creation of progress with inspiring, innovative solutions and to a trusting partnership towards our customers and partners with common benefits.
