Nyhet - 9 December 2015 09:32

BLDC with high power density

With the DB80, Nanotec presents an EC motor which – relative to its size – exhibits exceptionally high power density. Featuring a rated speed of 3000 rpm and a rated voltage of 48 V, this 8-pin motor is particularly suitable for applications which require a high degree of efficiency; for example in service robotics or automated guided vehicle systems. The DB80 has a flange size of 80 x 80 mm and is available with Hall sensors or encoder. Four lengths cover a performance range from 280 to 940 W.

Additional high-performance planetary gear systems can be mounted for high torques. Customer-specific versions with other windings or wave forms are also offered. Soon the DB80 will also be available with integrated electronics under the model name PD6-CB80.
