HMI Faceplates for Easy Switch Diagnos

Press Release   •   Feb 10, 2016 13:51 GMT

HMI faceplates for easy diagnostics and configuration are also available now for the advanced managed switches from the FL Switch 7000 series from Phoenix Contact. The switches support the Device Level Ring (DLR) protocol in an Ethernet/IP environment for nearly seamless switching times of less than 3 ms, as well as the Common Industrial Protocol (CIP).

HMI faceplates enable operating systems in Ethernet/IP networks to access important diagnostic information about the network, without programming effort, and to perform port-specific configurations in the field. Due to the preconfigured use of CIP information, commissioning is possible without programming work.

The HMI faceplates enable, among other things, full detection of changes in the machine network, such as the loss of a link to a port, power supply failure, or the activation of a DLR redundancy mechanism. This means that the user can act quickly when there is a problem and initiate the appropriate maintenance measures.

Phoenix Contact, founded over 80 years ago, is a leading manufacturer of electric connection and industrial automation technology. 14000 employees, 50 own sales companies and 30 sales partners worldwide ensure customer proximity.

Our work is dedicated to the creation of progress with inspiring, innovative solutions and to a trusting partnership towards our customers and partners with common benefits.
